Bench Top Reactors
As the name suggest, bench top reactors are very small glass reactors that are mounted on the bench top or table top. These reactors can be single stand alone reactors or can also have interchangeable set up.
Product Specifications
| Vessel Capacity | 250 mL to 5L |
| Temperature range | (-) 90 deg c to 200 deg c |
| Vessel type | Single ( Double wall) and Double (Triple wall) Jacket |
| Operating Pressure Range | Full vacuum to 0. 5 bar (g) |
| Interchangeable Pan | Yes |
| Interchangeable Stirrer | Yes |
| Delta T (Double wall reactor) | 110 deg c |
| Delta T (Triple wall reactor) | 60 deg c |
| Reactor bottom pan | |
| Jacket inlet and outlet connection size | Glass nozzle with SS connector |
| Glass top cover nozzle orientation | N1: Agitator; N2:Temperature probe holder; N3:Stopper for hand holder;N4:Condenser; N5:Dropping funnel |
| Reactor and lid connection | Quick release clamp. FEP encapsulated “O” ring |
| Drive | Stirrer, Flexible Stirrer shaft coupling (Bola), Seal Magnetic-SS / Hastelloy, PTFE Stirrer guide (imported) FLP/NFLP motor, with VFD /without VFD |
| Stirrer (MoC) | SS PTFE lined / Hastelloy/SS/Glass |
| Stirrer (type) | Anchor, Propeller, CBRT, Hydrofoil |
| Pressure Safety Valve | Optional , 0.5 bar |
| Temperature sensor | Direct contact type PTFE temperature sensor with Lemo connector along with adjustable height arrangement. |
| Other accessories | Specially designed vapour condenser cum reflux divider. |
| Graduated addition funnel | |
| Receiver flask | |
| Support structure | Specially designed for stirrer interchange arrangement |
